| LOKHUM (DELIGHT) BOILER | |
| CAPACITY : 100 Kg / BATCH | |
| DEPTH : 55 cm. | |
| DIAMETER : 90 cm. | |
| HEIGHT : 200 cm. | |
| WEIGHT : 620 Kg. | |
| Motor Power : 4 kw + 1kw = 5 Kw | |
| PARTS AND COMPONENTS: | |
| 1 | Motor |
| 2 | Spiral Bevel |
| 3 | Motor – Reductor |
| 4 | Tracked mixer shaft |
| 5 | Oval win |
| 6 | Electric hot oil system |
| 7 | Oil entrance hoose |
| 8 | Hot Oil Pomp |
| 9 | Steam way – Sempantin |
| 10 | Hoods and extractor fan |
| 11 | Oil entrance and exit |
| 12 | Engine Chassis |
| 13 | Boiler Chassis |
| 14 | Oil Entrance |
| 15 | Electric panel |
| 16 | The Throw gear and arms |
| 17 | Hidrolic throw |
| 18 | Unloading gate |
| MACHINE ELEMENTS AND VALUES | |
| 1 | R-S-T-Phase input warning light |
| 2 | Pako 16 A two-stage switch to M-1 |
| 3 | M-2 for 1 and 2 start button |
| 4 | M-2 to 9 A 1 and 2 contactors |
| 5 | M-2 swich |
| 6 | M-1, 4 kw – 5,2 Ps - 9 A 3-phase motor |
| 7 | M-2, 1 kw-1,3 ps – 2,25 A 3-phase motor |
